For Agents semiconductor laser machine

LM Semiconductors laser machine is the one-fourth traditional system dimension. Adopt a fully boarding structure for optical system features to prevent dust from entering the laser cavity. With a light path and focus instruction preview function to locate the product. The system is equipped with sophisticated three-dimensional table and the latest external water cooling system, run in a very low noise environment, temperature control is very precision, can be operated in a long-term. Our company have the self-knowledge right for laser marking software, which compatible with CORELDRAW, AUTOCAD, POTOSHOP file format and mark the text graphics etc, also support auto-coding, serial number, batch number, date, one-dimensional bar codes and two-dimensional code marking.Technical-parameters:Model:LM-50DLM-75DLM-100DLaser power:50W75W100WWave length:1064nm1064nm1064nmBeam quality:666Laser repetition frequency :50KHz50KHz50KHzStandard marking scope :110mm×110mm110mm×110mm110mm×110mmMatching marking scope :150×150mm 200×200mm 300×300mmEngraving depth:(Adjustable according to the material) :0.3mm0.4mm0.5mmMarking speed:7000mm/s7000mm/s7000mm/sMinimum line width:0.02mm0.02mm0.02mmMin. character size:0.25mm0.25mm0.25mmRepetition precision:±0.001mm±0.001mm±0.001mmSystem Power Consumption:2.5KW2.8KW3.3KWSupply voltage:220V/50Hz/15A220V/50Hz/20A220V/50Hz/25ACooling method:Built-in circulating water coolingBuilt-in circulating water coolingBuilt-in circulating water coolingStructure:One type / SplitOne type / SplitOne type / Split
